MIL-DTL-24695/1B(SH)
REQUIREMENTS:
1. Valve shall have a protective cap with secondary sealing provisions that withstands pressure equal to the proof
pressure rating of the valve. The protective cap shall include a security chain or equivalent to prevent loss of the
cap.
2. Fluid openings shall be sealed before packaging by the use of caps or plugs in accordance with NAS847.
3. Part number: As specified in table I, the part number shall consist of the basic number of this specification sheet
plus a dash number indicating end fitting, "A" for NiCu alloy or "C" for CRES pressure containing parts, and "L" if
lock wire hole is required.
Example:
M24695/1-1-C-L - Valve with 0.438-20 UNF thread fitting in accordance with ANSI/ASME B1.1, CRES pressure
containing parts, and lock wire hole.
M24695/1-2-A - Valve with M10 x 1.0 thread fitting in accordance with SAE MA2039-05, NiCu alloy pressure
containing parts, and without lock wire hole.
TABLE I. Vent and test valve identification of part number.
Part number
Fitting thread size
Inlet thread
Seal
Comment
M24695/1-1
0.438-20 UNF
ANSI/ASME B1.1
SAE AS3581-904
For SAE J1926-1 Port
M24695/1-2
M10 x 1.0
SAE MA2039-05
SAE MA3445A0080
For SAE MA2012-05 Port
CHANGES FROM PREVIOUS ISSUE: Marginal notations are not used in this revision to identify changes
with respect to the previous issue due to the extent of the changes.
Preparing Activity:
Navy SH
(Project 4810-2012-002)
