METRIC
MIL-DTL-24695/3B(SH)
25 September 2012
SUPERSEDING
MIL-V-24695/3A(SH)
29 December 1994
DETAIL SPECIFICATION SHEET
VENT AND TEST,
HOSE ASSEMBLY ADAPTER
This specification is approved for use by the Naval Sea Systems Command, Department of the Navy, and is
available for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the product described herein shall consist of this specification sheet and
MIL-DTL-24695. Graphical detail of the vent and test hose assembly adapter is provided on figure 1.
LOCKING ELASTOMER RING
12 mm X 1.5
HEX STK "D"
REVERSE BUTTRESS THDS
(ACROSS FLATS)
FITTING THD SIZE
BACKUP
SEE TABLE I
RING
"O" RING
"A"
3.40
3.35
7.3 MIN.
"C"
"B"
FIGURE 1. Vent and test hose assembly adapter.
AMSC N/A
FSC 4810
