MIL-DTL-24695/2B(SH)
NOTES:
1. Dimensions in millimeters (and inches).
2. Reverse (compression) buttress threads shall be as specified herein and as shown on the vent and test valve
configuration of MIL-DTL-24695/1 for the cap or internal threads.
Hose End
Fitting thread:
Major dia.: 12.605 - 12.715
(internal)
Pitch dia.: 11.915 - 12.025
Minor dia.: 11.375 - 11.485
3. Materials shall be in accordance with MIL-DTL-24695 (see requirement 3 below).
4. Tolerances ±0.2 millimeter (0.008 inch) except as noted.
5. Hose length tolerance: ±12 millimeters (0.47 inch).
FIGURE 1. Detail of vent and test valve hose assembly end fitting Continued.
REQUIREMENTS:
1. Torque required to connect the hose assembly to the vent and test valve shall be in accordance with
MIL-DTL-24695.
2. Hose ends shall be protected by plugs to prevent thread damage and dirt infiltration in accordance with NAS847.
3. Part number: The part number shall consist of the basic number of this specification sheet plus a dash number
indicating hose length (see table I) and "A" for NiCu alloy or "C" for CRES pressure containing parts.
Example:
M24695/2-03-C - 915 millimeter (3 feet) hose assembly with CRES pressure containing parts.
M24695/2-10-A - 3050 millimeter (10 feet) hose assembly with NiCu alloy pressure containing parts.
TABLE I. Dash numbers indicating hose length.
L
Dash no.
millimeters
feet
required
reference only
-01
305
1
-03
915
3
-06
1830
6
-10
3050
10
3
