MIL-V-47308A (MI)
4.5.1 Inspe ction lot. The lot size shall be not greater than the
quantity of items produced in one continuous operation utilizing the same
production processes for delivery for one contract or order.
Samples selected in accordance with 4.5
4.5.2 Inspection and tests.
shall be subjected to the inspections and tests in table III in that order.
TABLE III.
Quality conformance
inspection.
4.6 Method of inspection.
4.6.1 Examination of product.
Each valve shall be visually and
dimensionally inspected and polarity determined to assure conformance to 3.3,
3.4, 3.8 and 3.9.
4.6.2 Insulation resistance and dielectric strength.
A voltage of 1000
Vdc shall be applied across coil 1 and coil 2 for 15 seconds.
After 15
seconds, the resistance from point A, point B, or point C to the valve body
(see figure 1) shall be measured for conformance to 3.5.1.
4.6.3 Coil resistance.
The resistance across coil 1 and coil 2 shall
be measured for conformance to 3.5.2.
10
