MIL-V-47308A (MI)
REQUIREMENTS
3.
3.1 First article. When specified in the contract or purchase order
(see 6.2), a sample shall be subjected to first article inspection (see 4.4
and 6.3).
3.2 Materials. Materials to be used in the manufacture of the valve
shall be selected in accordance with the requirements of MIL-H-8775 for type
II components.
Design of the valve shall conform to figure 1 (see 4.6.1) .
3.3
Design.
3.3.1 Valve action. When voltage potential at pin A is positive with
respect to the potential at pin C and coils are series connected as shown on
the wiring diagram of figure 1, fluid flow shall be out of port 1 (see 4.6.1).
The valve shall be designed to operate with
3.3.2 Fluid media.
hydraulic fluid conforming to MIL-H-5606 (see 4.6.1).
Construction of the valve shall conform to MIL-H-
3.4 Construction.
8775 (see 4.6.1).
3.5
Performance.
The insulation
3.5.1 Insulation resistance and dielectric strength.
resistance between the coils and valve body shall be greater than 50 megohms
following a 15 second application of 1000 volts direct current (Vdc) (see
4.6.2).
The direct current (de) resistance of each coil
3.5.2 Coil resistance.
100 ohms (see 4-6.3).
shall be 1000
3.5.3 Coil app arent inductance. The greatest apparent inductance of
the two coils series connected shall be less than or equal to 12 henries (H)
with a coil current of one milliampere (ma) root mean square (rms) at 150
hertz (Hz) (see 4.6.4).
The valve shall withstand without external
3.5.4 Proof pressure.
leakage or permanent performance degradation, 1500 pounds force per square
applied to the pressure port, port 1 and port 2 with the return
inch
applied simultaneously to
port open for 2 minutes, followed by 1000
all ports for 2 minutes (see 4.6.5).
3.5.5 External leakage. There shall be no evidence of external
leakage, other than a slight wetting insufficient to form a drop at an
(see 4.6.6).
operating pressure of 1000
3
